Specifications
Able to Ship Small Parcel: No
Blade Color: Metallic
Blade Material: Aluminum
Brand: Schaefer
CFM (free air): 12120
CFM (high): 12120
CFM (low): 8750
CFM Calculation Standard: ANSI/AMCA Standard 230-99
CFM Range (Free Air): 10001 - 15000
CFM/Watt (free Air): 23.3
CFM/Watt Range (free air): 20.1 -25
Component Certifications: Motor - CSA
Cord: Included - Wired
Cord Length (feet): 10
Country of Origin: US
Description: (36CFO, PED36R-B)
Diameter (inches): 36
Drive Type: Direct
Fixed or Portable: Portable
Frequency (Hz): 60
Guard Color: White
Guard Material & Coating: Powder Coated Steel
Guard Spacing (inches): 1/2 OSHA
Max RPM: 1075
Mount Type Included: Pedestal
Nameplate Amps: 5.2/2.8
Number of Wings: 3
Oscillating: No
Phase: 1
Power (hp): 1/2
Product Color: White
Product Shipping Dimensions: (FAN) 41 X 41 X 15 / (PEDESTAL) 36 X 7 X 34
Product Weight (pounds): (FAN) 59 / (PEDESTAL) 28
Schaefer Performance Test No.: 675
Speed Control Compatible: No
Speeds: 2
Switch: On product
VFD Compatible: No
Voltage: 115
