Specifications
Air Velocity (@ 10'): 1100
Blade Color: Metallic
Blade Material: Aluminum
Brand: Schaefer
CFM (free air): 9600
CFM (high): 9600
CFM (low): 8500
CFM Calculation Standard: ANSI/AMCA Standard 230-99
CFM Range (Free Air): 5001 - 10000
CFM/Watt (free Air): 19.7
CFM/Watt Range (free air): 15.1 - 20
Component Certifications: Motor - UL/CSA/CE
Cord: Included - Wired
Cord Length (feet): 10
Country of Origin: US
Diameter (inches): 30
Drive Type: Direct
Fixed or Portable: Portable
Frequency (Hz): 60
Guard Color: Black
Guard Material & Coating: Powder Coated Steel
Guard Spacing (inches): 1/2 OSHA
Max RPM: 1075
Mount Type Included: Pedestal
Mount Type Recommended: NA
Nameplate Amps: 5.9
Number of Wings: 3
Opening Area (sq. ft.): NA
Oscillating: Yes
Phase: 1
Power (hp): 1/2
Product Color: Black
Rough-in Dimensions: NA
Schaefer Performance Test No.: 701
Sound Level (dBA @ 10'): 71
Speed Control Compatible: No
Speeds: 2
Switch: On product
VFD Compatible: No
Voltage: 115
