Kimo LV 107 Technical Features
Measuring element
Vane anemometer :LV107 : Hall effect sensorAmbient temp. : Pt100 class A
Display
2 lines - LCD - Size 50mm x 34.9mm single line, 5 digits w/ 7 segments - value single line, 5 digits w/ 16 segments - unit
Housing
Shock-proof made of ABS, IP54 protection
Keypad
Metal-coated with 5 keys
Cable
straight, lg. 200 mm (LV101)retractable, length 450 mm, up - 2.4 m when released
Conformity
electro magnetic compatibility (NF-EN-61326-1 guidelines)
Power
1 9 Volt alkaline 6LR61 battery
Operating temp.
(instrument). from 0 - 50 deg. C
Operating temp. probe
-20 - 80 deg. C
Storage temp.
Adjustable auto shut-off
0 - 120 min
Weight
190g
Languages
French, english
Kimo LV 107 Specifications
Measuring Units
Measuring Ranges
Accuracy*
Resolutions
AIR VELOCITY
m/s, fpm, Km/h
from 0.3 - 3 m/sfrom 3.1 - 35 m/s
±3% of reading ±0.1m/s±1% of reading ±0.3m/s
0.1 m/s
AIR FLOW
m3/h, cfm, l/s, m3/h
from 0 - 99999 m3/h
±3% of reading ±0.03 *area(cm2)
1 m3/h
AMBIENT TEMPERATURE
deg. C, deg. F
from -20 - +80 deg. C
±0.4% of reading ±0.3 deg. C
0.1 deg. C
