MATERIALS
Housing: High impact nylon
Hub: Shock-absorbing engineered co-polymer
Lifeline: Vectran core webbing, polyester jacket
Braking Mechanism: Stainless steel
Webbing:
- Vectran core, polyester jacket
- 1” wide x 0.06” thick (25.4mm x 1.5mm)
- 1” wide x 0.06” thick (25.4mm x 1.5mm)
Thread: Polyester
Connectors: See images below for details
TECHNICAL
Min. Working Capacity: 130 lb (59 kg)
Max. Working Capacity: See table below for capacity ratings
Working Length Capacity: 6 ft (1.8 m), 9 ft (2.74 m), 11 ft (3.35 m)
Max. Arrest Distance: 42 in (1.06 m)
Avg. Arresting Force: 1350 lb (6 kN) (when tested to ANSI Z359.14)
Max. Peak Arresting Force: (when tested to ANSI Z359.14) 900 lb (4kN) for 310 lb (140 kg) user and 1800 lb (8kN) up to 420 lb (190.5 kg) user (using the ANSI test method for Overhead SRL) 1,800 lb 8kN) (when tested to ANSI Z359.14)
Ultimate Strength: 3,000 lb (13.34kN)
